Feb 1st, 2022 Creative Sound Blaster X4 Review - A Great Sound Card, Now Even Better.Feb 2nd, 2022 God of War Benchmark Test & Performance Review.Feb 11th, 2022 Intel Core i3-12300 Review - World's Fastest Quad-Core.Retail boards based on this design (91) NameĤ GB, 290 mm/11.4 inches, Triple-slot, 2x DVI 1x DisplayPort 1x mini-HDMIģ06 mm/12 inches, Quad-slot, 1x DVI 1x HDMI 1x DisplayPortĢ67 mm/10.5 inches, 1x DisplayPort 3x mini-HDMIĢ79 mm/11 inches, 1x DisplayPort 3x mini-HDMI OpenCL 3.0 Vulkan 1.1 CUDA 3.0 Shader Model 5.1 GK104 GPU Notes L1 Cache is configurable from 16 KB up to 48 KB per SMX The card's dimensions are 256 mm x 111 mm x 38 mm, and it features a dual-slot cooling solution. GeForce GTX 680 is connected to the rest of the system using a PCI-Express 3.0 x16 interface. Display outputs include: 2x DVI, 1x HDMI, 1x DisplayPort. The GPU is operating at a frequency of 1006 MHz, which can be boosted up to 1058 MHz, memory is running at 1502 MHz (6 Gbps effective).īeing a dual-slot card, the NVIDIA GeForce GTX 680 draws power from 2x 6-pin power connectors, with power draw rated at 195 W maximum.
NVIDIA has paired 2,048 MB GDDR5 memory with the GeForce GTX 680, which are connected using a 256-bit memory interface. It features 1536 shading units, 128 texture mapping units, and 32 ROPs. The GK104 graphics processor is an average sized chip with a die area of 294 mm² and 3,540 million transistors. Even though it supports DirectX 12, the feature level is only 11_0, which can be problematic with newer DirectX 12 titles.
Built on the 28 nm process, and based on the GK104 graphics processor, in its GK104-400-A2 variant, the card supports DirectX 12.
The GeForce GTX 680 was a high-end graphics card by NVIDIA, launched on March 22nd, 2012.
